N2XSERGBY/NA2XSERGBY 3.6/6kV 6/10kV 8.7/15kV 12/20kV 18/30kV MEDIUM VOLTAGE Cu(AL) CONDUCTOR XLPE INSULATED MULTI-CORE STEEL TAPE ARMOURED POWER CABLE

Model Number:N2XSERGBY/NA2XSERGBY CU(AL)/XPLE/CTS/PVC/SWA/PVC
, 3.6/6kV 6/10kV 8.7/15kV 12/20kV 18/30kV
Kitengo: Kebo za Nishati/Kebo za Umeme/Kebo ya Viwanda
Mahali pa asili: XingTai, Uchina
Jina la Biashara: TIANHUAN
Certification ISO,CE,IEC,TUV

Minimum order quantity:5000 meters

WASILIANA NA SASA DOWNLOAD PDF

Maelezo

Lebo

Kigezo

Nom.Cross-section Eneo	overall kipenyo	cable Uzito	Upinzani wa DC at 20℃ Conductor min	Current Carrying Capacity at 30℃
Nom.Cross-section Eneo	overall kipenyo	cable Uzito	Upinzani wa DC at 20℃ Conductor min	In Air	In Ground
mm²	mm	km/kg	Ω/km	A
3×25	43	3660	0.727	133	132
3×35	45	4175	0.524	172	170
3×50	49	5260	0.387	205	201
3×70	53	6330	0.268	256	245
3×95	57	7555	0.193	312	294
3×120	60	8640	0.153	359	334
3×150	63	9840	0.124	409	375
3×185	68	11510	0.0991	468	424
3×240	76	14490	0.0754	552	492
3×300	82	17587	0.0601	627	552

N2XSERGbY 3.6/6kV

Nom.Cross-section Eneo	overall kipenyo	cable Uzito	Upinzani wa DC at 20℃ Conductor min	Current Carrying Capacity at 30℃
Nom.Cross-section Eneo	overall kipenyo	cable Uzito	Upinzani wa DC at 20℃ Conductor min	In Air	In Ground
mm²	mm	km/kg	Ω/km	A
3×25	48	4600	0.727	134	133
3×35	51	5220	0.524	173	171
3×50	54	5925	0.387	206	202
3×70	57	6985	0.268	257	246
3×95	62	8310	0.193	313	295
3×120	65	9415	0.153	360	335
3×150	68	10572	0.124	410	376
3×185	75	13015	0.0991	469	425
3×240	78	15424	0.0754	553	493
3×300	85	18210	0.0601	628	553

N2XSERGbY 6/10kV

Nom.Cross-section Eneo	overall kipenyo	cable Uzito	Upinzani wa DC at 20℃ Conductor min	Current Carrying Capacity at 30℃
Nom.Cross-section Eneo	overall kipenyo	cable Uzito	Upinzani wa DC at 20℃ Conductor min	In Air	In Ground
mm²	mm	km/kg	Ω/km	A
3×25	54	5432	0.727	134	132
3×35	56	5992	0.524	173	171
3×50	59	6723	0.387	206	202
3×70	63	7922	0.268	257	246
3×95	67	9210	0.193	313	295
3×120	70	10355	0.153	360	335
3×150	73	11530	0.124	410	376
3×185	79	14275	0.0991	469	425
3×240	84	16650	0.0754	553	492
3×300	90	19354	0.0601	629	554

N2XSERGbY 8.7/15kV

Nom.Cross-section Eneo	overall kipenyo	cable Uzito	Upinzani wa DC at 20℃ Conductor min	Current Carrying Capacity at 30℃
Nom.Cross-section Eneo	overall kipenyo	cable Uzito	Upinzani wa DC at 20℃ Conductor min	In Air	In Ground
mm²	mm	km/kg	Ω/km	A
3×35	61	6748	0.524	173	171
3×50	64	7588	0.387	206	202
3×70	68	8720	0.268	257	246
3×95	72	10075	0.193	313	295
3×120	76	12082	0.153	360	335
3×150	79	13325	0.124	410	376
3×185	84	15310	0.0991	469	425
3×240	89	17685	0.0754	553	492
3×300	95	20480	0.0601	629	554

N2XSEFGbY 12/20kV

Nom.Cross-section Eneo	overall kipenyo	cable Uzito	Upinzani wa DC at 20℃ Conductor min	Current Carrying Capacity at 30℃
Nom.Cross-section Eneo	overall kipenyo	cable Uzito	Upinzani wa DC at 20℃ Conductor min	In Air	In Ground
mm²	mm	km/kg	Ω/km	A
3×50	78	10,645	0.387	207	202
3×70	82	12,000	0.268	257	246
3×95	86	13,465	0.193	313	295
3×120	89	14.76	0.153	360	335
3×150	92	16,070	0.124	410	376
3×185	97	18,075	0.0991	469	425
3×240	101	20,550	0.0754	553	492
3×300	107	23,615	0.0601	629	554

N2XSEFGbY 18/30kV

Muundo wa Cable

● Conductor:Compact stranded copper conductor,CI.2 as per IEC 60228

● Skrini ya Kondakta: Semi-kondakta

● Insulation:XLPE rated at 90°C

● ID Tape:Red/Yellow/Black

● Metallic Screen:Copper Tape Screen

● Polyster Tape

● Separation Sheath(for armoured cable):PVC inner Sheath(Fully extruded)

● Armoring:Galvanized Steel Flat Armor

Galvanized Steel Tape

●Sheath:PVC or FR-PVC type ST2/ST8 to IEC 60502,black

Uteuzi wa Msimbo

YJ: XLPE insulation

V: ala ya PVC

22:Nyeti mbili za chuma za mabati-viini 3

62:Mkanda wa chuma cha pua mara mbili -1 msingi

ZR:Inastahimili moto

European Union:N2XSERGBY/NA2XSERGBY

Maombi

For installation in the ground, indoors,cable trunking and outdoors if increased mechanical protection is required or where high-pulling stresses may occur during installation or operation.

Kawaida

International:IEC 60502,EC60228,(IEC60332-3forZR-YJV22,ZR-YJV62only)

China:GB/T12706,(GB/T18380-3forZR-YJV22,ZR-YJV62only)

European standard:DIN VDE0276-620,HD620S2,IEC/EN 60228,IEC/EN 60502-2

Flame Retardant according to IEC/EN 60332-1-2

Indonesian Standard:Conductor:SNI IEC 60228/Insulation:SNI IEC 60502-2

Viwango vingine kama vile BS,DIN na ICEA juu ya ombi

Data ya Kiufundi

Rated voltage:3.6/6KV6/10KV 8.7/15KV 12/20KV 18/30kV

Kiwango cha Juu cha Joto la Kondakta:chini ya kawaida (90℃),dharura(130℃)au mzunguko mfupi usiozidi hali ya 5s (250℃).

Min.Ambient Temp.-20°℃,Installation Temp.0℃

Min.Bending Radius:15×cable OD kwa msingi mmoja
